PE FOAM EXPANSION JOINT FILLER

PE Foam Expansion Joint filler is a semi-rigid, U.V. resistant, high performance closed cell polyethylene foam joint filler in sheet form.
It is suitable for use as an expansion joint filler in concrete, brick, blockwork and isolation joints, where a readily compressible low load transfer joint filler is required.

PE Foam Expansion Joint filler is non-tainting and therefore suitable for use in potable water retaining and water excluding structures.
  • PE FOAM EXPANSION JOINT FILLER

  • PARKWAY FOAM

Color:
Size:
Denisty:
Availability:
Quantity:

 PE FOAM EXPANSION JOINT FILLER



Cell Structure Closed-cell
Thickness 10mm / 15mm / 20mm/ 25mm/50mm/ Customized
Size 2000mm x 1000mm
Density  40kg/m3 /  60kg/m3 / 100kg/m3


WHAT IS PE FOAM EXPANSION JOINT FILLER


PE Foam Expansion Joint filler is a semi-rigid, U.V. resistant, high performance closed cell polyethylene foam joint filler in sheet form.

It is suitable for use as an expansion joint filler in concrete, brick, blockwork and isolation joints, where a readily compressible low load transfer joint filler is required.

PE Foam Expansion Joint filler is non-tainting and therefore suitable for use in potable water retaining and water excluding structures.






Water-resistant-fabric





Water Resistant

rebound



Good Resilience



shock absorption




Shock Absorption

Corrosion resistance

Corrosion resistance

Sound insulation

Sound Insulation

Anti-aging

Anti Aging






USAGES OF PE FOAM EXPANSION JOINT FILLER


  • Structural expansion joints in concrete, brick and block work.

  • Isolation joints to infill panels

  • Bridge joints, abutments, pier hinge joints

  • As a back-up support for sealants

  • As a bond breaker for sealants over bituminous joint fillers

  • Anti-vibration pads for machinery bases

微信图片_202204011152307


微信图片_20220401115228
微信图片_202204011152309


ADVANTAGES OF PE FOAM EXPANSION JOINT FILLER


  • No absorbent, closed cell

  • Readily compressible

  • Rot proof

  • Deformable - accepts temperature cycle with minimal load transfer

  • No-tainting, suitable for potable water

  • Excellent recovery after compression

  • Resilient- will not distort under normal load with wet concrete

  • Easily worked- can be cut with a knife

  • Economical in use

  • Bitumen free- non bond breaker required for sealants

  • Chemical resistant - inert to most dilute acids and alkalis, resistant to oil and hydrocarbons


APPLICATIONS OF PE FOAM EXPANSION JOINT FILLER


PE Foam Expansion Joint filler is a compressible joint filler in sheet form, used to form and fill expansion joints.

In concrete

PE Foam Expansion Joint filler can be placed against formwork on the concreting side prior to placing the first section of concrete and is left in place on removal of the formwork. The subsequent pour is then cast directly against the PE Foam Expansion Joint filler. The board is then cut back later to form the sealing slot.

In blockwork and brick

PE Foam Expansion Joint filler should be installed, whilst laying brick or blockwork, in such a way that a sealing slot, of the required dimensions in formed.



Who we are ?


Parkway Foam is a leading foam production and processing factory, we can provide a variety of foam products, such as EVA foam, PE foam, neoprene foam, EPDM foam and NBR foam.

At the same time, we have advanced processing capabilities to convert foam into the products you need.



What kinds of foam materials we can supply ?


We can supply :EVA foam, PE foam, XPE foam, IXPE foam, CR foam, EPDM foam, Neoprene foam, SBR foam, NBR foam, Micro-cell soft PVC foam. All of them we can supply in sheet and roll.



What's the processing capacity we have ?


1. Cutting - cutting the size as per client’s request

2. Slicing - Slicing the thickness as per client’s request

3. Lamination - hot melt film lamination, flame lamination, and pressure-sensitive adhesive lamination

4. Laser Vibrator - New type cutting machine, can cut the foam drawing without open molds

5. Die cutting - Open molds as per your design then at first, use die cutting machine to produce, it’s quicker than laser vibrator.

6. Compression Molding - Compression molding is a process we utilizes for the manufacturing of three-dimensional molded foam and foam composite parts. It is an ideal process for making parts that have intricate features, require very defined part geometry, have varying wall thicknesses or need to be held to critical dimensional tolerances.

7. Engraving machine - Usually to make tool box insert and packing insert as per client’s requests.

8. Silk-screen printing - Print logos and patterns on the surface of foam products

9. Adhesive backing - Gluing on the surface of the foam with liners. Usually produce foam tapes and other products need to stick on.



Where is our facility located ?


Our factory is located in Changzhou city, Jiangsu Province. One hour driving to Shanghai Port.



How to get samples ?


Send enquiry to sales@parkwayfoam.com, with your details of the foams need, we will check reply in 24 hours.



As a professional manufacturer of foam, we have professional production equipment, rich production and processing experience, and can meet the needs of customers in different industries.
We are committed to continuously providing excellent products and services to customers worldwide.
